2.5”x6” Swivel Ended Double Acting Hydraulic Ram

2.5”x6” Swivel Ended Double Acting Hydraulic Ram

$175.99 USD
$209.99 USD $175.99 USD
Sale Sold out

2.5x6 swivel ended dual action hydraulic ram.


SPECIFICATIONS

Double Acting

Bore x Stroke 2.5" x 6"

Barrel Thickness 0.25"

Gland Retainer Threaded in gland

Pressure 3000 PSI max.

Rod Dia. 1.5"

Column Load 3000 PSI max. @ full extension

Ports SAE 8

Retracted Length 13.5"

Shpg. 17 lbs.

END MOUNTINGS

Rod End Swivel-Ball

Ball Width 0.97"

Ball O.D. 2.25"

Pin Hole 1"

Base End Swivel-Ball

Ball Width 0.97"

Ball O.D. 2.25"

Pin Hole 1"

Materials

Only the best quality

Shipping & Returns

Free shipping in lower 48 states.

Care Instructions

View full details

  • Free Shipping

    All prices include shipping within the lower 48 states. We can ship out of the US but there may be additional charges for shipping.
